Theory of Computation

BCS1110

Dr. Ashish Sai

📅 Week 3 Lecture 1
💻 bcs1110.ashish.nl
📍 EPD150 MSM Conference Hall

Quick Recap

Week Lecture 1 Lecture 2
Week 1 Introduction (Computational Thinking) Hardware (Transistors, Gates (AND, OR, NOT), Combinational Circuits, ALU, CPU, Computing Hardware)
Week 2 Algorithms (Flowcharts, Pseudocode) Operating Systems
This Week Theory of Computation Theory of Computation
Week 4 Computer Networks Computer Networks
Week 5 Information Security Information Security

Plan for Today

  • Formal Language Theory
  • Finite Automata
  • FSA Examples
  • Deterministic Finiate Automaton

Why Do We Need to Know This? 🤔

  • Computer science is more than just:
    1. Writing code 💻
    2. Compiling code 🔄
    3. Fixing bugs in code 🐞
    4. Compiling again 🔄
    5. And finally going for a walk 🚶 because you've ended up with even more bugs than you began with 🤦

"Computer science at its core is all about problem solving!" 💡

What problems can we solve with a computer?

Theory of Computation (TOC)

  • TOC answers a fundamental question:

    "What problems can we solve with a computer?"

  • Importance of TOC:
    • Knowing what a computer can and cannot do helps us solve problems more efficiently.
    • Some problems cannot be solved by a computer, regardless of the algorithm.

Halting Problem

A decision problem: will the given program terminate or run forever?

Can you write an automated program that could answer this question without running the code?

Computers are Messy

Computers are Messy

That messiness makes it hard to rigorously say what we intuitively know to be true: that, on some fundamental level, different brands of computers or programming languages are more or less equivalent in what they are capable of doing.

MacOS vs Windows, C vs C++ vs Java vs Python

We need a simpler way of discussing computing machines

An automaton (plural: automata) is a mathematical model of a computing device

Automata are Clean

Computers are messy

Automata are Clean

Why build models?

  • Mathematical simplicity
    • It is significantly easier to manipulate our abstract models of computers than it is to manipulate actual computers
  • Intellectual robustness
    • If we pick our models correctly, we can make broad, sweeping claims about huge classes of real computers by arguing that they're just special cases of our more general models

Why build models?

  • The models of computation we will explore in this class correspond to different conceptions of what a computer could do

  • Finite Automata (today’s lecture) are an abstraction of computers with finite resource constraints

    • Provide upper bounds for the computing machines that we can actually build
      • Deterministic Finite State Automata (DFA)
      • Non-deterministic Finite State Automata (NFA)

What problems can we solve with a computer?

Problems with Problems

  • Before we can talk about what problems we can solve, we need a formal definition of a “problem.”
  • We want a definition that
    • corresponds to the problems we want to solve,
    • captures a large class of problems, and
    • is mathematically simple to reason about
    • No one definition has all three properties

Formal Language Theory

Part 1/4

Strings (informal)

  • Sequence of any symbols (“characters”)
    Example:
    “hello” “1234” “🧑‍🎓🧑‍🎓🧑‍🎓🧑‍🎓”

Strings (more formally)

  • An alphabet is a finite set of symbols called characters
  • Typically, we use the symbol Σ (sigma) to refer to an alphabet
  • A string over an alphabet Σ is a finite sequence of characters drawn from Σ
  • Example: If , here are some valid strings over Σ: a, aabaaabbabaaabaaaabb
    • The empty string has no characters and is denoted by ε

Languages (informal)

  • Sets of strings
    • Examples
      • {hello, 1234, 🧑‍🎓🧑‍🎓🧑‍🎓🧑‍🎓, ε}
      • {10110, 0110, 10}

Languages (more formally)

  • A formal language is a set of strings.
  • We say that L is a language over Σ if it is a set of strings over Σ
  • Example: The language of palindromes over Σ = {a,b,c} is the set
    • {ε, a, b, c, aa, bb, cc, aaa, aba, aca, bab, ... }
    • The set of all strings composed from letters in Σ is denoted
    • Formally, we say that L is a language over Σ if L ⊆

Quick Quiz

Which statements are true?

  • Alphabets are sequences of characters
  • Languages are sets of strings
  • Strings are sets of characters
  • Characters are individual symbols
  • Languages are sequences of characters

Recap

  • Languages are sets of strings
  • Strings are sequences of characters
  • Characters are individual symbols
  • Alphabets are sets of characters

The Model

  • Fundamental Question: For what languages L can you design an automaton that takes as input a string, then determines whether the string is in L? (Essentially pattern recognition)

    • The answer depends on the choice of L, the choice of automaton, and the definition of “determines.”

    • In answering this question, we’ll go through models of computation and see how this seemingly abstract question has very real and powerful consequences.

To Summarise

  • An automaton is an idealized mathematical computing machine (I use the terms machine and automata interchangeably)

  • A language is a set of strings, a string is a (finite) sequence of characters, and a character is an element of an alphabet

What problems can we solve with a computer?

Finite Automata

Part 2/4

A finite automaton is a simple type of mathematical machine for determining whether a string is contained within some language

Each finite automaton consists of a set of states connected by transitions

Automata to determine if a heatwave occurred

  • Input: String of weather data
  • 🇬🇧 Heatwave: temperature ≥ 28 C for 2 consecutive days

Automata to determine if a heatwave occurred

  • Input: String of weather data
  • 🇬🇧 Heatwave: temperature ≥ 28 C for 2 consecutive days

Automata to determine if a heatwave occurred

  • Input: String of weather data
  • 🇬🇧 Heatwave: temperature ≥ 28 C for 2 consecutive days
  • = { all strings containing 11}
  • The automaton above recognises
    • Accepts everything within and rejects everything else

A Simple Finite Automaton

A Simple Finite Automaton

Each circle represents a state of the automaton

A Simple Finite Automaton

One special state is designated as the start state

A Simple Finite Automaton

The automaton is run on an input string and answers “yes” or “no”

0 1 0 1 1 0

A Simple Finite Automaton

The automaton now begins processing characters in the order in which they appear

0 1 0 1 1 0

A Simple Finite Automaton

Each arrow in this diagram represents a transition. The automation always follows the transition corresponding to the current symbol being read

0 1 0 1 1 0

A Simple Finite Automaton

After transitioning, the automaton considers the next symbol in the input

0 1 0 1 1 0

A Simple Finite Automaton

0 1 0 1 1 0

Now that the automaton has looked at all this input, it can decide whether to say “Yes” or “No”

The double circle indicates that this state is an accepting state, so the automation outputs “Yes”

A Simple Finite Automaton

Input: 1 0 1 0 0 0

A Simple Finite Automaton

Input: 1 0 1 0 0 0

This state is not an accepting state (it is a rejecting state), so the automaton says “No”.

A Simple Finite Automaton

Input: 11011100

Try it yourself!

Does this automaton accept or reject?

A Simple Finite Automaton

Input: 11011100

To Summarise

  • A finite automaton is a collection of states joined by transitions
  • Some state is designated as the start state
  • Some states are designated as accepting states
  • The automaton processes a string by beginning in the start state and following the indicated transitions
  • If the automaton ends in an accepting state, it accepts the input
  • Otherwise, the automaton rejects the input`

Short break

Do not leave your seats (5 min)

FSA Examples

Part 3/4

Just Passing Through

Input
1 1 0 1

Just Passing Through

Input
1 1 0 1

A finite automaton does not accept as soon as it enters an accepting state

A finite automaton accepts if it ends in an accepting state

What Does This Accept?

No matter where we start in the automaton, after seeing two 1’s, we end up in accepting state

What Does This Accept?

No matter where we start in the automaton, after seeing two 0’s, we end up in accepting state

What Does This Accept?

This automaton accepts a string in {0, 1} if and only if the string ends in 00 or 11

The language of an automaton is the set of strings that it accepts

  • If D is an automaton that processes characters from the alphabet Σ, then L(D) is formally defined as:

    • L(D) = {w ∈ Σ | D accepts w}

Quick Quiz

  • How many of the following statements are true?
    • A language of an automaton can have an infinitely long string (or many of them) in it
    • A language of an automaton can contain infinitely many strings
    • A language of an automaton can contain no string

A Small Problem

Input:
0 1 1 0

A Small Problem

Input:
0 1 1 0

A Small Problem

Input:
0 0 0

A Small Problem

Input:
0 0 0

The Need for Formalism

  • In order to reason about the limits of what finite automata can and cannot do, we need to formally specify their behaviour in all cases

  • All of the following need to be defined or disallowed:

    • What happens if there is no transition out of a state on some input?
    • What happens if there are multiple transitions out of a state on some input?

Deterministic Finite Automaton

Part 4/4

DFAs

  • A DFA is defined relative to some alphabet Σ
  • For each state in the DFA, there must be exactly one transition defined for each symbol in Σ
    • This is the “deterministic” part of DFA
    • There is a unique start state
    • There are zero or more accepting states
Deterministic Finite Automaton (Formal Definition)

D = (Q, Σ, δ, , F)
- Q is the set of states [Q = { , , } ]
- Σ is the alphabet [Σ = {1,0} ]
- δ is the transition function [I will cover this on Thursday]
- is the start state
- F is an accepting state [F = { } ]

How many of these are DFAs over {0, 1}?

Is this a DFA?

Drinking Family of Alpaca

Designing DFAs

  • At each point in its execution, the DFA can only remember what state it is in

  • DFA Design Tip: Build each state to correspond to some piece of information you need to remember

    • Each state acts as a “memento” of what you're supposed to do next
    • Only finitely many different states means only finitely many different things the machine can remember

Recognizing Languages with DFAs

L={ w ∈ {a,b} | w contains aa as a substring }

Recognizing Languages with DFAs

L={ w ∈ {a,b} | w contains aa as a substring }

More Elaborate DFAs

L = { w ∈ {a,,/} | w represents a Java-style comment }

  • Let’s have the a symbol be a placeholder for “some character that isn’t a star or slash.”

  • Try designing a DFA for comments! Here’s some test cases to help you check your work:

Accepted:

                             /*a*/ /**/ /***/ /*aaa*aaa*/ /*a/a*/

Rejected:


                                /** /**/a/*aa*/ aaa/**/aa /*/ /**a/ //aaaa

More Elaborate DFAs

L = { w ∈ {a,,/} | w represents a Java-style comment}

More Elaborate DFAs

L = { w ∈ {a,,/}* | w represents a Java-style comment }

See you on Thursday! 👋🏼

Why do we have to know this? What I am going to teach you in next two lectures will less practical when you compare it with topics like programming, algorithms but it is important. Computer scinece is more than: - 1. Writing code - 2. Compiling code - 3. Fixing bugs in code - 4. Compiling again - 5. And finally going for a walk because now you have more bugs than when you started As I mentioned in week 1, computer science at its core is all about problem solving! This is where Theory of computation really shines! In TOC, we try and answer one very fundamental question: What problems we can solve with a computer? Why do we want to know this? Because knowing what a computer can and cannot do, can help us solve problems more efficiently. Because there are problems that a computer cannot solve no matter how much time we spend coming up with an algorithm. Look at the halting problem, Alan Turing proved that a computer cannot solve it. We use something called Models of Computations to mathematically prove if such a problem can or cannot be solved.

The first thing you need to ask is what type of Computer?

We can use something called Models of Computation to mathematically answer questions like these!

Before we can talk about problems, we need to know what we mean by a problem. In short, I have problems with problems

We want to define our problems in a more formal manner so that we can reason about it using automaton

For each string in the language, we say that the string belongs to this language So for the language {10, 001} We know, 10 ∈ {10, 001} 001 ∈ {10, 001} 1 ∉ {10, 001} 010 ∉ {10, 001} 0001 ∉ {10, 001}

This is ⊆ a symbol of subset

- 1. False (it is a set) - 2. True - 3. False (it is sequence not a set) - 4. True - 5. False (are a set of strings)

The automaton accepts 11, 110, 0110

- A language of an automaton can have an infinitely long string (or many of them) in it: **False**. Automata, by definition, process strings in finite time. Therefore, they cannot accept or recognize infinitely long strings. - A language of an automaton can contain infinitely many strings: **True**. For example, consider the language of all strings over the alphabet {a, b} that have an even number of a's. This language contains infinitely many strings (e.g., aa, aab, aaba, aabaa, ...), but each string is of finite length. - A language of an automaton can contain no string: **True**. An automaton can recognize the empty language, which contains no strings at all. Additionally, the language can contain the empty string (denoted as ε or λ), which is a string of length 0.
