Theory of Computation

BCS1110

Dr. Ashish Sai

🗓️ TOC - Lecture 2
💻 bcs1110.ashish.nl

Plan for Today

  • Recap from TOC Lecture 1
  • Tabular DFAs
  • Regular Languages
  • NFAs
  • Designing NFAs
  • (if time permits) Tutorial Questions

Recap From Last Time

Old MacDonald Had a Symbol, 🎶 Σ-eye-ε-ey∈, Oh! 🎶

  • Here’s a quick guide to remembering which is which:
    • Typically, we use the symbol Σ (sigma) to refer to an alphabet
    • The empty string is length 0 and is denoted ε (epsilon)
    • In set theory, use ∈ to say “is an element of”
    • In set theory, use ⊆ to say “is a subset of”

DFAs

  • A DFA is a
    • Deterministic
    • Finite
    • Automaton

Recognizing Languages with DFAs

L = { w ∈ {a,b} | w contains aa as a substring }

DFAs

  • A DFA is defined relative to some alphabet Σ (sigma)
  • For each state in the DFA, there must be exactly one transition defined for each symbol in Σ
    • This is the “deterministic” part of DFA
  • There is a unique start state
  • There are zero or more accepting states

Tabular DFAs

Part 1/4

Deterministic Finite Automaton (Formal Definition)
  • Input: String of weather data
  • 🇬🇧 Heatwave: temperature ≥ 28 C for 2 consecutive days

DFA Definition

D = (Q, Σ, δ, , F)

  • Q is the set of states [Q = { , , }]
  • Σ is the alphabet [Σ = {1,0}]
  • δ is the transition function
  • is the start state
  • F is an accepting state [F = { }]

Transition Function:

DFA Definition

D = (Q, Σ, δ, , F)

  • Q is the set of states [Q = { , , }]
  • Σ is the alphabet [Σ = {1,0}]
  • δ is the transition function
  • is the start state
  • F is an accepting state [F = { }]

Transition Function:
1 0

Which table best represents the transitions for the following DFA?

Table A

0 1

Table B

0 1
Tabular DFAs
0 1
  • Stars indicate accepting states
  • First row is the start state

Code Demo

public class DFASimulator {

    private static final int kNumStates = 4; // 4 states based on the table
    private static final int kNumSymbols = 2; // 2 symbols (0 and 1) based on the table

    private static final int[][] kTransitionTable = {
        {1, 0},
        {3, 2},
        {3, 0},
        {3, 3}
    };

    private static final boolean[] kAcceptTable = {
        true,
        false,
        false,
        true
    };

    public static boolean simulateDFA(String input) {
        int state = 0;
        char[] inputArray = input.toCharArray();
        for (int i = 0; i < inputArray.length; i++) {
            char ch = inputArray[i];
            if (ch != '0' && ch != '1') {
                throw new IllegalArgumentException("Invalid input symbol: " + ch);
            }
            state = kTransitionTable[state][ch - '0'];
        }
        return kAcceptTable[state];
    }

    public static void main(String[] args) {
        String testInput = "1011"; // Example input
        boolean isAccepted = simulateDFA(testInput);
        System.out.println("The input " + testInput + " is " +
            (isAccepted ? "accepted" : "rejected") + " by the DFA.");
    }
}

The Regular Languages

Part 2/4

  • A language L is called a regular language if there exists a DFA D such that
  • If L is a language and L(D) = L, we say that D recognises the language L

The Complement of a Language

  • Given a language L ⊆ Σ , the complement of that language (denoted L’) is the language of all strings in Σ that aren't in L
  • Formally:

Complements of Regular Languages

  • A regular language is a language accepted by some DFA
  • Question: If L is a regular language, is L’ necessarily a regular language?
  • If yes → if there is a DFA for L, there must be a DFA for L’
  • If no → some L can be accepted by a DFA, but L’ cannot

Complementing Regular Languages

L = { w ∈ {a,b}* | w contains aa as a substring }

L’ = { w ∈ {a,b}* | w does not contain aa as a substring }

More Elaborate DFAs

L = { w ∈ {a,*,/} | w represents a (multi-line) Java-style comment }

More Elaborate DFAs

L’ = { w ∈ {a,*,/} | w doesn’t represent a (multi-line) Java-style comment }

Closure Properties

  • Theorem: If L is a regular language, then L’ is also a regular language
  • Thus, regular languages are closed under complementation

Time Out

(Not A Break)

Ever felt you weren't good enough to be in STEM? Afraid of being "found out" because you don't think you belong?

NFAs

Part 3/4

NFAs

  • An NFA is a

    • Nondeterministic
    • Finite
    • Automaton

  • Structurally similar to a DFA, but represents a fundamental shift in how we'll think about computation

(Non)determinism

  • Deterministic: at every point, exactly one choice

    • Accepts if that sequence leads to an accepting state

  • Nondeterministic: machine may have multiple possible moves

    • Accepts if any path leads to an accepting state

A Simple NFA

has two transitions defined on 1!

A Simple NFA

Input: 01011

Non-Deterministic Finite Automaton (Formal Definition)

D = (Q, Σ, δ, , F)

  • Q = { , , , }
  • Σ = {0,1}
  • δ = transition function
  • = start state
  • F = { }

A Simple NFA: Transition Function

A Simple NFA: Transition Function
State 0 1
{ } { , }
{ } { }
{ } { }
{ } { }

A More Complex NFA

If an NFA needs to make a transition when none exists, that path dies and does not accept

As with DFAs:
L(N) = { w ∈ Σ | N accepts w }

What is the language of the NFA above?

  • A) {01011}
  • B) { w ∈ {0,1} | w contains at least two 1s }
  • C) { w ∈ {0,1} | w ends with 11 }
  • D) { w ∈ {0,1} | w ends with 1 }
  • E) None of these, or two or more of these
  • Answer: A and C → so E

NFA Acceptance

  • N accepts w if some path reaches an accepting state
  • N rejects w if no path does
  • Easier to prove acceptance than rejection

ε-Transitions

  • NFAs may follow ε-transitions (no input consumed)
  • May follow any number at any time

Input: b a a b b

ε-Transitions

  • NFAs are not required to follow ε-transitions

Suppose we run on input 10110. Which are true?

  • There is at least one accepting computation
  • There is at least one rejecting computation
  • There is at least one dead computation
  • NFA accepts 10110
  • NFA rejects 10110

Designing NFAs

Part 4/4

Designing NFAs

  • Embrace nondeterminism
  • Guess-and-check model:
    • Nondeterministically guess information
    • Deterministically check correctness

Guess-and-Check

L = { w ∈ {0,1} | w ends in 010 or 101 }

Guess-and-Check

L = { w ∈ {0,1} | w ends in 010 or 101 }

Guess-and-Check

L = { w ∈ {0,1} | w ends in 010 or 101 }
  • Nondeterministically guess when to leave start
  • Deterministically check correctness

Guess-and-Check

L = { w ∈ {0,1} | w ends in 010 or 101 }
  • Nondeterministically guess when to leave start
  • Deterministically check correctness
Guess-and-Check

L = { w ∈ {a,b,c} | at least one of a, b, or c is not in w }
Guess-and-Check

L = { w ∈ {a,b,c} | at least one of a, b, or c is not in w }

Guess-and-Check

L = { w ∈ {a,b,c} | at least one of a, b, or c is not in w }

Guess-and-Check

L = { w ∈ {a,b,c} | at least one of a, b, or c is not in w }

NFAs and DFAs

  • Any DFA is also an NFA
  • So every DFA language is also an NFA language
  • Question: Can every NFA language be accepted by a DFA?
  • Surprisingly: Yes!

See you in the lab! 👋🏼
